Antari W-515D 1500 W Pro Fogger W-DMX
Product Description
The W-Series Stage Foggers from Antari are designed to meet the rigorous demands of stage and touring ideal to be used for very large venues, outdoor events, movie production and many other applications. The precision lies with optoelectronic liquid sensor (OPTO). When sensing there’s insufficient liquid, the pump will stop working, and the production of fog will be ceased until it senses the re-filling of the liquid again. An LCD digital control module is equipped to the W-Series, allowing the users to set the volume control, timer control, and DMX functions to precision.
Antari’s W-Series transforms digital wireless control of stage effect machine navigation into a simple, natural control of the hand and fingers. This premium-performance series is specially upgraded for professional users who demand true “Plug-In and Play” operation for stage fog machines. All the unnecessary wires are eliminated leaving you a transmitting controller in your hand to send out the commands.
The innovative smart-intelligence lies with the learning-mode of the wireless function. The receiver can memorize up to 5 sets of frequencies and can receive signals from any registered transmitter. Besides the included wireless control it is also equipped with on board Wireless DMX from Wireless Solutions Sweden.
A square, durable housing design that gives the W series a refined look and eases transport. The design offers protection against stray water or spilLED drinks. There are two professional versions: W-515 (1500 W) and W-530 (3000 W).
Electrical Specifications and Connections
Power Supply 240 V AC 50-60 Hz
Power Consumption 1450 W
Power Connector In powerCON Blue
DMX Connector XLR 3P In/Out, XLR 5P In/Out
DMX Connector In XLR 3P, XLR 5P
DMX Connector Out XLR 3P, XLR 5P
Heater 1450 W
Warm-up Time 10 min
Mechanical Specifications
Output Capacity560 m³/min
Output Direction Forward
Housing Aluminium, Metal
Colour Gray
Fluid Consumption 100 ml/min
Fluid Tank Capacity 6 L
Length (mm) 561 mm
Height (mm) 264 mm
Width (mm) 278 mm
Weight 14.5 kg
IP Rating IP20 (indoor use only)
Control and Programming
Control Mode DMX, Manual, Remote, Stand Alone, Timer
DMX Channels 1
Wireless Wireless DMX
Product Properties
LED Indicators Power
Rigging
Safety Attachment Yes
Thermal Specifications
Maximum Ambient Temperature 40 °C
Included Items
Included Cables powerCON cable
Included Remotes W-2
