Description
The M - Liner 1040 is an ultra high power LED based moving head beam bar with smart and compact stylish fireproof housing with a smooth, fast and quiet TILT movement. The beam angle is 2° for each LED with sharp beam effect. It features 10*40W 4-in-1 RGBW LED sources with pixel mapping capability which not only allows you to create an endless range of color variations, but also to use each LED of the array as a pixel in order to draw all kinds of graphic images that change dynamically both in shape and color. It provides variable speed shutter/strobe effect, virtual color macro effect, dynamic patterns, static patterns to it’s users for easy operation. It comes with kinds of DMX channel profiles. The M - Liner 1040 supports DMX, RDM (Remote Device Management). The fixture’s exterior housing is beautifully balanced basing on a modern design philosophy with supremely harmonious interior structure for remarkable control. The sculpted body of the M - Liner 1040 achieves more than just a striking look. The 2*1/4 turn fastening omega clamps, available for vertical and horizontal plug-in, make installations fast and easy.It’s applicable for large scale live concerts, TV productions, road shows, clubs, etc.
10 x 40W high efficency 4-IN-1 RGBW LED Life Span 50000H
2,° Beam Angle
0-100% Smooth linear LED dimming with fine control
0-20Hz high speed strobe effect with variable speed
Sophisticated 4 colors RGBW mixed
Pixel mapping capability with each LEDs controllable individually
Sharp beam effect
Preset color macros and patterns with variable speed
Preset foreground color options for patterns
Flicker free operation for broadcast TV and FILM
TILT movement 230°(8/16 bit), photoelectric reset and automatic error correction
DMX512 with RDM / Master-Slave / Auto / Sound modes
High Efficient low noise self adjusting fan cooling system
Lamp: 10 x 40W high efficency 4-IN-1 RGBW LED
LED life: 50000 hours
Input voltage: AC100-240V 50/60Hz
Power consumption: 960W
Control Mode: DMX512, Master/slave, Sound, Auto Mode, RDM
DMX Channel Modes: 7/13/43 Channel
Beam angle: 2°
Dimmer: 0-100% Smooth linear LED with ?ne control
Focus: High resolution motorized
Scan: Smooth, fast and precise resolution for TILT movement 270° e 16Bit
Strobe: 0-25T/sec high speed
Display: LED display with 4 control buttons
Colors: Sophisticated 4 colors RGBW mixed
Pixel mapping: available with each LEDs controllable individually
Preset: color macros, patterns, foreground and Backgrond with variable speed
Lense: high efficiency acrylic
Housing: Flame-retardant plastic and Alluminium
Internal Running Temperature: 0 ÷ 40°C
Dimensions (WxDxH): 1000(W) * 283.7(D) * 230(H)mm
Weight: 13.6 kg
Package Dimensions (WxDxH): 1300(W) * 290(D) * 380 (H)mm
Package Weight: 25.5 kg
