Description
Hear yourself with clarity. The dB Technologies FMX10 Active Floor Monitor makes sure nothing will drive a wedge between you and perfect monitoring.
Precise, professional, and plenty of power. The FMX10 boasts advanced processing with custom linear phase FIR filters, reproducing your sound with zero phase distortion for maximum impact. It doesn't stop there though. Eight intelligent presets allow you to instantly optimise your sound for any application in an instant.
A unique front-rear metal grille protects the FMX10's premium coaxial transducers, as well as the rotatable horn. Whilst a sturdy wooden enclosure makes this speaker tough enough for any stage. And when it comes to transportation, the FMX10's lightweight design and ergonomic handles make moving it completely hassle-free.
Monitoring the right way
Completely adaptable monitoring. The dB Technologies FMX10 is built to meet your needs. From rotatable horns, to a built-in ergonomic handle and pole mount. The FMX10 is versatile in every sense of the word. The FMX10's eight built-in presets allow you to ensure that you're always sounding your best. From Live Monitor, Coupled Monitors, Male or Female Singer, and Antifeedback to name a few, you can be prepared for any situation.
Advanced processing
Intelligent and effective. The FMX10's integrated DSP takes care of your sound to ensure that it's delivered with outstanding clarity. Simply select one of the eight presets to suit your needs, and the monitor will do the rest. The DSP also takes advantage of linear phase FIR filters. These ensure that your sound is reproduced with zero phase distortion or delay distortion. So you can enjoy crystal-clear, uniform sound and exceptional system optimisation every single night.
Built for the road
It takes more than a solid cabinet to achieve the reliability you want. And that's exactly why FMX monitors have been built with meticulous attention to detail. From the robust plywood enclosures, to the unique front-rear grille design, and the use of premium components. Every aspect of these rugged monitors has been crafted to give you the durability you deserve.
And when it comes to living with your monitor through day to day use, you'll feel free. An ergonomic handle has been built into the bottom side of the cabinet, enabling you to transport, maneuver, and position your monitor with ease. Plus, you can mount your FMX monitor on a speaker stand or pole thanks to an integrated 36mm pole receptacle on the side panel. And no matter what position you use your monitor in, you'll still have full access to the controls on the opposite side panel.
Features
- 2-way active stage monitor with a coaxial design
- 400W RMS Class-D amplifier drives a 10'' LF woofer and 1'' HF transducer
- Custom rotatable horn design for optimising directivity
- Advanced DSP with linear phase FIR filters for even, intelligible sound
- Eight on-board presets adapt the EQ for different needs
- Intuitive operation with exceptional sonic results
- Innovative front-rear grille design protects your components
- Robust plywood cabinet for maximum durability
- 36mm pole receptacle provides an easy mounting solution
- Ergonomic handle allows for hassle-free maneuverability
Specifications
- Speaker Type: 2-way active coaxial stage monitor
-
Frequency Response:
- -10dB: 57Hz - 19kHz
- -6dB: 65Hz - 16.5kHz
- Maximum SPL: 125dB
- HF Transducer: 1'' exit, 1'' voice coil
- Horn: Rotatable
- Directivity: 60° x 90° (H x V)
- LF Transducer: 10'' diameter, 2'' voice coil
- Crossover: 1800Hz (24dB/oct)
- Amp Class: Class-D
- Power: 400W (RMS) / 800W (peak)
- PSU Technology: SMPS
- Controller: DSP 28/56-bit
- AD/DA Converter: 24-bit/48kHz
- System Presets: 8 presets
- Limiter: Peak, RMS, Thermal
- Advanced DSP Function: FIR filters
- Controls: DSP programs rotary encoder, Line/Mic switch, Input Sensitivity level
- Signal Inputs: 1 x balanced XLR connector
- Signal Out/Link: 1 x balanced XLR connector
- Mains Connection: VDE
-
Housing:
- Material: Plywood
- Design: Multifunctional
- Grille: Full metal
- Handles: 1 x integrated on bottom side
- Pole Mount Receptacle: 36mm
- Operating Voltage: 220-240V, 50-60Hz
- Power Draw: 0.8A (at 1/3 of full power in maximum use conditions)
- Dimensions: 390mm x 268mm x 411mm / 15.35'' x 10.55'' x 16.18'' (W x H x D)
- Weight: 11.3kg / 24.9lbs
- SKU: FMX10
