Penn Elcom PDU16-UK32 2U 32 Amp AC Rack Mount PDU with 8 x UK Sockets
Product Description
2U 32 Amp AC Rack Mount PDU with 8 x Universal Sockets, Overload Protection & Power Monitoring
2U high Horizontal Mounting unit designed to provide versatile hook-up for the distribution of AC power within Multimedia Theatre & Touring rack applications.
Circuit A:
- Main Input - C-FORM 240V 32A IP44 Panel Mount Appliance Inlet
- Protection - Illuminated Circuit Breaker overload protection between dual 16A sockets
- Output - C-FORM 240V 16A IP44 Panel Mount Appliance Outlet
Circuit B:
- Output - 8 UK sockets useable with plugs from the UK with a Maximum Combined Load 16A.
- Protection - Illuminated Circuit Breaker 16A overload protection
- LCD Monitor - LCD Power Monitor giving Voltage, Current, Power and Energy Levels.
- Earth Link - M4 Screw Terminal for Rack Grounding
Usage:
- Nominal Voltage: 110V-230V
- Usable Voltages: 110V-240V full range
- Frequency: 50/60HZ full range
- Max. A/C Output: Current 32A
- Case Size: 140mm x 98mm x 430mm (O.A. 483mm)
- Weight: 2.8kg
All components used in this conform to current RoHS, CE & UL certification - E&OE (EMI:EN55022 (CISPR22) Class B; EN61000-3-2,3 EMS:EN61000-4-2,3,4,5,6,8,11; Light industry level, criteria A)
| Number of Sockets | 8 |
|---|---|
| Plug Type | UK |
| Size (U) | 2U |
| Weight | 2.8kg |
