Pioneer DJ PLX-CRSS12 Professional Direct Drive Turntable with DVS Control

The PLX-CRSS12 is a professional digital-analog hybrid turntable with brand-new features to help DJs take their performances to the next level. It’s the world’s first deck to offer DVS control of digital music via DJ software as well as analog playback of vinyl records, and it improves on the sound quality of the popular PLX-1000 professional turntable.

• Tone-arm-free DVS control
• Feeling adjustment
• Performance Pads and OLED display
• Evolved, high-quality sound
• Replaceable MAGVEL CLAMP
• Robust and elegant design in matte black colour
• Serato DJ Pro and rekordbox compatibility

General

• Power requirements:  AC 110 V – 240 V, 50 Hz / 60 Hz
• Power consumption:  8 W
• Power consumption (standby):  0.5 W
• Weight:  12.2 kg / 26.9 lb
• Maximum Dimensions (W × D × H):  453 × 353 × 159 mm / 17.8” x 13.9” x 6.3”
• Tolerable operating temperature:  +5 °C – +35 °C (+41 °F – +95 °F)
• Tolerable operating humidity:  5% – 85% (no condensation)

Turntable

• Drive method:  Servo type direct drive
• Motor:  3-phase brushless DC motor
• Braking system:  Electronic brake
• Rotation speed:  33¹/3 rpm, 45 rpm
• Rotation speed adjustment range:  ±8%, ±16%, ±50%
• Wow and flutter:  0.15 % or less WRMS (JIS WTD)
• S/N ratio:  65 dB (DIN-B)
• Turntable:  Aluminum die-casting diameter: 332 mm
• Starting torque:
  • High: 0.45 N·m (4.5 kgf·cm) or more
  • Mid: 0.32 N·m (3.2 kgf·cm)
  • Low: 0.2 N·m (2.0 kgf·cm)
• Start time:  0.3 seconds (at 33¹/3 rpm)
• Brake time:
  • Max: 3.5 seconds
  • Mid: 1.0 seconds
  • Min: 0.5 seconds or less

Tone Arm

• Arm type:  Universal type S-shape tone arm, gimbal-supported type bearing structure, static balance type
• Effective length:  230 mm
• Overhang:  15 mm
• Tracking error:  Within 3°
• Arm height adjustment range:  6 mm
• Stylus pressure variable range:  0 g – 4.0 g (1 scale 0.1 g)
• Proper cartridge weight:  2.5 g – 12 g *Cartridge weight includes the mounting screws and nuts.
• When shell weight is used:  2.5 g – 5.5 g
• When only balance weight is used:  5 g – 9 g
• When sub weight is used:  8.5 g – 12 g

Inputs/Outputs

• PHONO output terminal
  • RCA pin jacks: 1 set
• USB terminal
  • Type-C: 1 set
