Radial ProD2 Stereo Passive DI Box

RadialSKU: 002389

Price:
Sale price£149

Description

At the heart of the Radial ProD2 stereo DI box is a design featuring two high performance Eclipse ET-DB2 transformers. These deliver a frequency performance of 20Hz to 20kHz and are able to withstand tremendous signal levels without distortion. Unlike an active circuit that can overload when the signal exceeds the rail voltage, transformer based DI boxes saturate. This creates a pleasing effect, naturally rounding out the tone and acting like a subtle limiter-particularly beneficial when working with digital pianos, samplers and drum machines that can produce excessive dynamics.

The ProD2 is designed and built to handle the rigors of professional touring. A 14-gauge steel ultra rigid i-beam frame eliminates stress on internal circuitry, with an innovative book-end design creating a protective zone around the connectors and switches. A full bottom no-slip pad adds mechanical isolation and electrical insulation to further reduce the opportunity for noise.

With a warm soundlegendary build quality and compact design, the Radial ProD2 is an excellent choice for studio recording or hitting the road.



Specifications



  • Audio circuit type: Passive, transformer based
  • Number of channels: Dual channel (Stereo)
  • Frequency response: 20Hz ~ 18.5KHz (± 0.2dB)
  • Dynamic range: 128dB
  • Maximum input: +18dB @ 20Hz
  • Total harmonic distortion: 0.01% from 20Hz~20kHz @-10dB
  • Phase deviation: 1° @ 100Hz; 8° @ 20Hz
  • Input impedance: 140k Ohms, unbalanced
  • Output impedance: 150 Ohms, balanced
  • Transformer: Radial RT-DBI, 12:1 ratio
  • Shield: Faraday, mu-metal can
  • Input pad: -15dB
  • 180° polarity reverse: Inverts absolute phase
  • Ground lift: Disconnects pin-1 at XLR output
  • XLR configuration: AES standard (pin-2 hot)
  • Connectors: 1/4" in & thru, XLR-M out
  • Construction: 14 gauge steel chassis & outer shell
  • Finish: Baked enamel
  • Size: (W x H x D) 70 x 108 x 44mm (2.75? x 4.25? x 1.75")
  • Weight: 0.54kg (1.2lbs)
  • Shipping Size: W x H x D: 102 x 76 x 165mm (4.00" x 3.00" x 6.50")
  • Shipping Weight: 0.61 kg (1.35 lbs)
  • Power: Passive, no power required
