Showtec Stellar UF-1000 1000w Upright Fogger
Product Description
The Stellar UF-1000 is an upright fog machine that can mimic the popular CO₂ effect. It has a robust, modern design and is equipped with a 1000-watt heater. The unit can be used in any orientation and it has built-in RGB LEDs that can be used to change the colour of the fog, expanding its creative possibilities. A clear LCD display aids manual control and other control options include DMX and an optional remote control. For best results, we recommend using Showgear fog fluid and why not add a delightful scent too?
Electrical Specifications and Connections
Power Supply 220-240 V AC 50 Hz
Power Consumption 1100 W
Power Connector In Power Pro Blue
DMX Connector XLR 3P In/Out, XLR 5P In/Out
DMX Connector In XLR 3P, XLR 5P
DMX Connector Out XLR 3P, XLR 5P
Remote Connector Jack
Heater 1000 W
Warm-up Time 9 min
Mechanical Specifications
Output Capacity 700 m³/min
Output Direction Up, Down, Forward
Housing Metal
ColourDark Gray, Silver
Fluid Consumption 150 ml/min
Fluid Tank Capacity 2 L
Length (mm) 344 mm
Height (mm) 216 mm
Width (mm) 362 mm
Weight 9.9 kg
IP Rating IP20 (indoor use only)
Control and Programming
Control Mode DMX, Local Control, Remote
DMX Channels 1, 2, 3, 5, 7
Display LCD
Product Properties
Cooling Convection
Source
Light Source Type LED
Light Source Power 3 W
LED Colour Type R, G, B, A
Rigging
Safety Attachment Yes
Thermal Specifications
Maximum Ambient Temperature 40 °C
Maximum Surface Temperature 60 °C
Included Items
Included Cables Power Pro Cable
Showtec - Stellar UF-1000 Upright Fogger. Product Code 61113 from Highlite International on Vimeo.
