Wharfedale Pro Typhon AX15 15" Active Speaker

Versatile, powerful and durable, Typhon active loudspeakers are perfect for on-stage or for fixed installations where power, clarity and reliability are essential.

This model is the largest in the Typhon family at 15" with a powerful 770w continuous power and 1540w peak. In addition, all models in the Typhon series are IP54 rated offering a degree of protection against splashes and dust.

Key Features

• 15″ Bi-amplified active loudspeaker
• 1.75″ HF compression driver
• 770 w Continuous
• 1540 w Peak
• 130 dB Max SPL @ 1 meter
• Huge 3.0″ LF voice coil

• Frequency Response (+/-3dB): 45Hz-20kHz
• Frequency Range (-10 dB): 40Hz-20kHz
• Maximum SPL (peak@1m): 130dB
• Sensitivity @ 1W / 1m): 99dB
• Size (mm / inches): 381mm / 15"
• Voice-Coil Size (mm / inches): 75mm / 3.5”
• Rated Impedance: 4Ω
• HF Driver Type: Compression Driver
• Coil Size (mm / inches): 44mm / 1.75"
• Exit Size (mm / inches): 25mm / 1"
• Diaphragm Material: Titanium
• Rated Impedance: 8Ω
• Nominal Coverage (H x V): Hybrid Symmetry Horn 100°x80°
• Amplifiers: 2 x Class D
• Power Rating: 1540 W Peak (1300 W LF + 240 W HF), 770 W Continuous (650 W LF + 120 W HF)
• Height: 697.7 mm / 27.5"
• Width Front: 480 mm / 18.9"
• Width Rear: 326mm / 12.8"
• Depth: 400mm / 15.7"
